ABS-ESD7
ABS-ESD7 combines the strength and durability of ABS with the electrostatic dissipative (ESD) properties of carbon, making this material particularly suitable for applications where a static charge could be dangerous or problematic. Other applications for this material include end-use components, industrial equipment and jigs, and fixtures for the assembly of electronic components.
기술 사양
| Maximum part dimensions | 914 x 610 x 914 mm 406 x 355 x 406 mm (online orders) |
| Standard accuracy | ±0.15% (with a lower limit on ±0.2 mm) |
| Layer thickness | 0.18 – 0.33 mm 0.25 (online orders) |
| Minimum wall thickness | 0.8 mm 1.2 mm (online orders) |
| Minimum detail size | 0.3 mm |
| Interlocking or moving parts | Yes |
| Internal channels | Yes |
| Surface structure | Rough surface with visible layers |
데이터시트
| 매개 변수 | 가치 | 구성 단위 | 방법 |
| ASTM D792 | 1.04 | g/cm³ | |
| ASTM D638 | 36 | MPa | |
| ASTM D638 | 2,400 | MPa | |
| ASTM D790 | 61 | MPa | |
| ASTM D790 | 2,400 | MPa | |
| ASTM D256 (Notched, Izod) | 28 | J/m | |
| ASTM D638 | 3 | % | |
| ASTM D648 (@1.82 MPa) | 82 | °C | |
| ASTM D257 | 3.0*10⁹ | Ohm-cm | |
| ASTM D257 | 10⁶ | Ohm | |
| DSC (SSYS) | 161 | °C |
Actual values may vary with build conditions and in relation to the part’s geometry and orientation.
Please get in touch with our team for more information and guidance.
Finishing degrees
The right finish can transform your print into a product. Explore the post-production finishes we offer for this material. If you have any questions or special requests, get in touch with us.
