Material
PerFORM
A resin with ceramic particles, PerFORM produces strong, stiff parts with high thermal resistance. It is ideal for functional prototypes for demanding applications such as wind tunnel tests and high-heat tests in the aerospace and automotive industries. PerFORM's superior sidewall quality and excellent detail resolution also make it a good choice for rapid tooling for injection molding.
Technical specifications
| Maximum part dimensions | 800 x 800 x 585 mm |
| Standard accuracy | ±0.2% (with a lower limit of ±0.2 mm) |
| Layer thickness | 0.1 mm |
| Minimum wall thickness | 1 – 3 mm depending on part dimensions |
| Minimum detail size | 0.5 mm |
| Interlocking or moving parts | No |
| Internal channels | Yes, but support structures may remain inside channels |
| Surface structure | Smooth surface with visible building layers; off-white material |
Datasheet
| PARAMETER | VALUE | UNIT | METHOD |
| ASTM D792 | 1.61 | g/cm³ | |
| ASTM D638 | 68 | MPa | |
| ASTM D638 | 10,500 | MPa | |
| ASTM D790 | 120 | MPa | |
| ASTM D790 | 10,000 | MPa | |
| ASTM D256 (Notched, Izod) | 17 | J/m | |
| ASTM D638 | 1.1 | % | |
| ASTM D2240 | 94 | Shore D | |
| ASTM D648 (@1.82 MPa) | 82 | °C | |
| ASTM E1545 | 72 | °C |
Actual values may vary with build conditions and in relation to the part’s geometry and orientation.
Please get in touch with our team for more information and guidance.
Finishing degrees
The right finish can transform your print into a product. Explore the post-production finishes we offer for this material. If you have any questions or special requests, get in touch with us.
Support marks removed
- Supports removed
- Cured
- Support marks sanded with P240
- Building layers still visible
- Not available for online orders
Normal
- Supports removed
- Cured
- A-surface/both sides are sanded with P240
- Sandblasted
- Building layers not visible
- Not available for online orders
Primer + paint A-side/2-side (dead matte, 10% gloss)
- Supports removed, support marks still visible
- Cured
- A-side/both sides are sanded with P400
- Primer paint sprayed on the A-side/both sides (light gray)
- A-side/both sides are sanded (wet) with P800
- Dead matte paint (10% gloss) sprayed on the A-side/both sides. Painted according to RAL specifications
- Not available for online orders
Primer + paint A-side/2-side (matte, 30% gloss)
- Supports removed, support marks still visible
- Cured
- A-side/both sides are sanded with P400
- Primer paint sprayed on the A-side/both sides (light gray)
- A-side/both sides are sanded (wet) with P800
- Matte paint (30% gloss) sprayed on the A-side/both sides. Painted according to RAL specifications
- Not available for online orders
Primer + paint A-side/2-side (satin, 50% gloss)
- Supports removed, support marks still visible
- Cured
- A-side/both sides are sanded with P400
- Primer paint sprayed on the A-side/both sides (light gray)
- A-side/both sides are sanded (wet) with P800
- Satin paint (50% gloss) sprayed on the A-side/both sides. Painted according to RAL specifications
- Not available for online orders
Primer + paint A-side/2-side (high gloss, 90% gloss)
- Supports removed, support marks still visible
- Cured
- A-side/both sides are sanded with P400
- Primer paint sprayed on the A-side/both sides (light gray)
- A-side/both sides are sanded (wet) with P800
- High-gloss paint (90% gloss) sprayed on the A-side/both sides. Painted according to RAL specifications
- Not available for online orders
Primer + paint A-side/2-side (soft touch)
- Supports removed, support marks still visible
- Cured
- A-side/both sides are sanded with P400
- Primer paint sprayed on the A-side/both sides (light gray)
- A-side/both sides are sanded (wet) with P800
- Soft-touch paint (transparent coating) sprayed on the A-side/both sides. Painted according to RAL specifications
- Not available for online orders
Primer + paint A-side/2-side (fine texture)
- Supports removed, support marks still visible
- Cured
- A-side/both sides are sanded with P400
- Primer paint sprayed on the A-side/both sides (light gray)
- A-side/both sides are sanded (wet) with P800
- Fine-texture paint (matte color paint with fine texture) sprayed on the A-side/both sides. Painted according to RAL specifications
- Not available for online orders
Primer + paint A-side/2-side (spatter)
- Supports removed, support marks still visible
- Cured
- A-side/both sides are sanded with P400
- Primer paint sprayed on the A-side/both sides (light gray)
- A-side/both sides are sanded (wet) with P800
- Spatter paint (matte color paint with coarse texture) sprayed on the A-side/both sides. Painted according to RAL specifications
- Not available for online orders
Additional finishes
Additional finishes are available on request:
- Primer ready to paint
- Primer + paint (texture D30/D50)
- Sealing varnish
- Glass-fiber reinforced
- Chrome look
- Metal plating technical
- Metal plating cosmetic
To discuss your needs, please get in touch via the link below.
